Description
What Makes this Engine Different?
- The Dual Stage Canister Air Filter is the biggest different between the FX541 and the FS541.
- This engine comes without a muffler. It should be ordered seperately from the manufacturer of your mower. (If you need a muffler, feel free to call us)
- The charging system on this engine is a clutch coil style system.
Features
- Overhead V-Valve
- 90º V-Twin
- Internally vented carburetor
- Rotating grass screen
- Dual stage canister air filter
- Metal engine cover
Specs
| Brand | Kawasaki |
| Part # | FX541V-DS01S |
| Shipping Weight | 89.7 lbs. |
| Crankshaft Diameter | 1″ |
| Crankshaft Length | 3-5/32″ |
| Starter Type | Recoil |
| Max RPM | 3600 |
| Displacement | 603cc |
| Ignition System | Electronic Spark |
| Lubrication System | Pressurized |
| Oil Capacity | 1.8 qt. |
| Fuel Type | Gasoline |
| Cooling System | Air |
| Compression Release | Yes |
| Max Torque (ft./lbs) | 32.1 |
| Oil Filter | Yes |
| Cylinders | 2 |
| Cylinder Bore | Cast Iron Liners |
| Bore x Stroke | 2.9″ x 2.8″ |
| Crankshaft Orientation | Vertical |
| Grade | Commercial |
| Warranty | 3 Year |
